Just KNIME It!
Prove your KNIME knowledge and practice your workflow building skills by solving our weekly challenges! Can you become one of our top Just KNIME It! KNinjas?
Creating a Report on Movies
Challenge 20
Level: Medium
Description: For this challenge, you will leverage KNIME’s reporting capabilities to create a neat PDF document containing summaries and visual analyses of a movie dataset. Movies from each decade should be analyzed separately, one decade per page.
Within each decade:
(1) what average budget was spent per genre?
(2) what was the average revenue per genre?
(3) what were the main features of its top 5 movies?
Do your best to enhance the report visualization (e.g., use format managers, colors, and head/footer). Hint: Use the KNIME Reporting extension to solve this challenge.
Author: Armin Rudd
Dataset: Movie Data in the KNIME Community Hub
Remember to upload your solution with tag JKISeason3-20 to your public space on KNIME Community Hub. To increase the visibility of your solution, also post it to this challenge thread on KNIME Forum.
We will post our solution to this challenge here next Tuesday.
Previous Challenges
Level: Easy
Description: Sports analytics is a growing field, and Formula 1 analytics is a part of it. Let’s perform a comprehensive data analysis to gather insights into both historical team performances and the dynamic shifts in driver positions throughout the thrilling 2021 season. Explore the given datasets and build visualizations that highlight the top 5 2021 teams and driver position changes. For the latter, create a dynamic visualization showing how drivers position changed after each round. Hint: All datasets available for this challenge should be used.
Author: Keerthan Shetty
Dataset: Formula 1 Data in the KNIME Community Hub
Solution Summary: To tackle this challenge, we start by combining data from constructors (e.g., BMW or Ferrari) with results data. After some preprocessing, we are able to visualize how many points each one of the top 5 constructors has accumulated. In parallel, we combine data from drivers, races, and results to dynamically visualize, for the 2021 season, how the drivers' ranking has changed from race to race.
Solution Details: To visualize all points each top 5 constructor has accumulated, we start by using two instances of the CSV Reader node to read constructors and results data. We join these datasets with the Joiner node and then group it by constructor name, summing all their corresponding points (GroupBy node). We then select the top 5 constructors based on their points (Top k Row Filter node), sort them (Sorter node), and visualize the points total for them with the Bar Chart node. We add different colors to the constructors in this visualization with the Color Manager node, mostly for aesthetic reasons. In parallel, we use two instances of the CSV Reader node to ingest data on drivers and races. We combine these datasets with the results data using two instances of the Joiner node. Next, we use the Row Filter node to focus exclusively on the 2021 season, and the Column Filter node to only keep information on drivers, how many points they made per race, and race dates. With this information, we use the Animated Bar Chart component to visualize how the drivers' ranking changes race by race, based on their points.
Level: Hard
Description: You work as a researcher creating models to identify whether a breast tumor is benign or malign, based on anonymized patient data. Besides obtaining a classifier that works very well for both benign and malign cases, you must be able to explain how different feature values impact your results. Experiment with LIME and visualization techniques to explain your predictions and make your research more transparent. Hint: Learn more about this problem's data attributes here.
Author: Keerthan Shetty
Dataset: Breast Tumor Data in the KNIME Community Hub
Solution Summary: To tackle this problem, we start by lightly preprocessing the data and then building a random forest classifier to predict whether a tumour is benign ('B') or malign ('M'). We then sample two instances categorized with very high confidence (one originally labeled as benign and the other as malign) and use LIME to see how the different instance features account for their predictions. At the end of our solution, we create visualizations to better interpret the impact of the features.
Level: Medium
Description: Birds like to travel and are often flying in big groups to different parts of the globe depending on the season. This week, your goal is to identify patterns in data about birds migrating from North America. You should isolate the initial and final locations of each bird and plot them on a map to visualize their migration path. Additionally, create a map visualization to determine which continent all the birds ultimately migrated to.
Author: Keerthan Shetty
Dataset: Bird Migration Data in the KNIME Community Hub
Solution Summary: To solve this challenge, we start by grouping the bird migration data per bird, using their local identifiers. We manipulate the data further and create geometries for the starting point and final destination of every bird's migration. We then visualize these geometries for each bird.
Level: Medium
Description: You are the architect behind an innovative vocal assistance device, and your initial goal is to process user reviews and uncover insights about 'sound quality’. To this end, you decide to use 4-grams to discover frequently mentioned words near the term "sound quality”. What trends emerge from the 4-gram frequencies? What is the top 4-gram? Hint: The NGram Creator node can come in handy here!
Author: Michele Bassanelli
Dataset: User Reviews Data in the KNIME Community Hub
Solution Summary: After reading the reviews and preprocessing them to remove punctuation and stopwords, we create 4-grams and filter them to only keep those that contain the term "sound quality". The most frequent 4-gram with this term is "pleasantly surprised sound quality".
Solution Details: To tackle this challenge, we use the File Reader node to read the reviews. Next, we transform them into type Document with the String to Document node: this is usually the first step for text mining in KNIME. We preprocess the reviews to remove punctuation (Punctuation Eraser node), numbers (Number Filter node), and stopwords (Stop Word Filter node) inside the Preprocessing metanode. We then use the NGram Creator node to create 4-grams for all preprocessed reviews, only keeping those that contain the term "sound quality" (Row Filter node). We sort the NGram corpus by frequency and find out that the 4-gram "pleasantly surprised sound quality" is the most popular.
Level: Easy
Description: You are a social scientist researching childcare in the European Union. The data you are currently examining contains the percentage of children under 3 years old that are cared by formal arrangements other than by the family, in various European countries. Is the overall trend increasing or decreasing? In what country is childcare the most common? And in what country it is the least common? Check for more information on the data here.
Author: Emilio Silvestri
Dataset: Childcare Data in the KNIME Community Hub
Solution Summary: To tackle this challenge, we pivot the data to get yearly childcare percentages for different countries. We then use different visualization strategies to see trends in childcare for the countries.
Solution Details: After reading the European Union childcare data and its metadata with the CSV Reader node, we use the Value Lookup node to replace country codes with country names, making the data easier to understand. Next, we use the Pivot node to get yearly childcare percentages for each one of the countries separately -- that is, each country turns into a separate column in the data, with yearly percentages corresponding to rows. We use the Box Plot node to visualize how these percentages are distributed per country (Denmark has the highest median value) and the Stacked Area Chart node to plot temporal trends for all countries. Overall, this last visualization suggests that certain countries are relying less on childcare in recent years, probably a lingering consequence of the COVID-19 pandemic.
Level: Medium
Description: You are a data scientist asked to analyze an avocado dataset by your team. The task at hand is to pick a specific avocado type in the whole of the US and forecast its daily average prices. To do that, you should train, apply, and score an ARIMA model. Do you see any seasonality in the line plot or autocorrelation plots? Do you think a seasonal ARIMA (SARIMA) would perform better? For your model, visualize forecasts and compute scoring metrics.
Authors: Roberto Cadili, Swetha Kannan, and Corey Weisinger
Dataset: Avocado Price Data in the KNIME Community Hub
Solution Summary: To tackle this problem, we focus on "conventional" avocado types, aggregate their prices per day, and then visually search for autocorrelation patterns that may indicate seasonality. The plots do not suggest strong seasonality patterns for the prices of avocados, but we still use a SARIMA model to learn and forecast the prices. We use a line plot to contrast the actual prices of avocados in the data we held out for testing against the forecasted prices generated by the model, and the predictions are rather close -- especially up to April.
Solution Details: After reading the data with the CSV Reader node, we filter out any rows that do not correspond to "conventional" avocado types and also sort the data by date (Data Preprocessing metanode). We use the Date&Time Aggregator node to get the average price per date, and then partition the data (70% for training, 30% for testing) using the Partitioning node. We send the training data to the SARIMA Learner node, setting the AR Order (p) as 2, the I Order (d) as 1, the MA Order (q) as 4, and the Seasonal Period (s) as 2. Configuring these parameters requires experimenting with different values, and then checking which ones lead to the best forecasts over the test data. We use the SARIMA Predictor node to generate forecasts, join them with the original values using the Joiner node, and then assess the quality of the forecasts visually, with the Line Plot node, and more analytically with the Numeric Scorer node.
Level: Easy to Medium
Description: You work in the contracts department of a software company and are asked to detect fraudulent (or wrong) contracts based on their contract value. Given the PDF versions of the contracts, you need to extract their contract value (and, optionally, any other fields you find useful) and detect outliers among them. You can either use simpler outlier detection techniques, such as those based on statistics or visualization, or more advanced ones based on machine learning.
Author: Lada Rudnitckaia
Dataset: Contract data in the KNIME Community Hub
Solution Summary: After ingesting and processing the contracts in PDF format, and isolating their contract values, we identify outliers via IQR (interquartile range), and box plot and histogram visualizations. Through these techniques, two contracts seem to be fraudulent based on their unusually large values.
Solution Details: We start our solution by parsing the PDF contracts with the PDF Parser node. Next, the Document Data Extractor node extracts text from each PDF. In parallel, we use sequences of Cell Splitter nodes to isolate contractual information, including their values. We then use the Column Appender node to add these new columns with extracted information to the initial contract table, and apply the Table Manipulator node to filter out and rename columns. At this point of the workflow, we only keep information on contract IDs and their corresponding values. This simplified table is then sent to a component named Outliers Detection, which uses a combination of nodes Numeric Outliers, Tile View, Box Plot, and Histogram nodes) to extract numeric outliers in different ways -- visually and statistically.
Level: Medium
Description: Did you know that August 2nd is International Beer Day? To celebrate one of the world’s oldest beverages, you are tasked with retrieving all worldwide brewery data from the OpenBreweryDB REST API, which provides data on the breweries in paginated responses. Build a loop that makes successive requests to each page of the API until all data is retrieved.
Not interested in beer? Feel free to use any API of your choice! Find more public APIs here: https://publicapis.io/
Author: Lada Rudnitckaia
Solution Summary: To tackle this challenge, we get the total number of breweries, calculate how many pages there are, and create a loop that extracts all brewery data page by page. We finish our solution with a paginated table view for the brewery data.
Solution Details: After getting the number of breweries with the GET Request and JSON Path nodes, we use the Math Formula node to compute the total number of pages (which is 42), given that the number of results per page is 200. With the Table Row to Variable node we turn the computed number of pages into a flow variable, and then use it to parametrize a loop (Counting Loop Start and Loop End nodes). Inside the loop, we get the number of the current page and add it to the base of a URL using the Math Formula (Variable) and String Manipulation (Variable) nodes. After that, a second instance of the GET Request node is used to retrieve data from the current page, which is then parsed and ungrouped (JSON Path and Ungroup nodes). When the loop ends, information for all pages has been collected. This information is sent to a visualization component that, with the Table Manipulator and Table View nodes, creates a simple tabulated interface for the brewery data.
Level: Easy
Description: The 2024 Summer Olympics start this week: are you ready for some on-theme trivia? Here are three questions to test your knowledge:
1. Which country has the highest average number of medals (gold, silver, and bronze combined) per athlete, across all Summer Olympics?
2. Which sport made its debut at the Rio 2016 Olympics?
3. Who holds the title of the oldest gold medalist of all time?
If you're not sure about the answers, don't sweat it: we've got a handy dataset that covers the entire history of the Games for you. Before you know it, you'll be standing on the virtual podium as the trivia champion, ready to take home the gold!
Author: Michele Bassanelli
Dataset: Olympics Data on KNIME Community Hub
Solution Summary: To answer question 1, we group the data to get (1) the number of medals per country and (2) the number of athletes per country. We then compute the ratio between (1) and (2) and get 'Russia' as the answer. For question 2, we group the data by year and sport, get all sports that were part of the Olympics up until 2012, and then compare this list with the sports that were part of the 2016 Summer Olympics. The sport that is present in the latter but not in the former, 'Rugby 7', started in 2016. Finally, for question 3 we filter the data to only take gold medalists into account and sort them by age. This leads us to the name of 'Charles Jacobus' as the answer.
Solution Details: After reading all datasets with CSV Reader nodes, we tackle question 1 by joining them on region/team with the Joiner node, creating a new column that indicates what athletes are medalists (Rule Engine node), and then computing the ratio between the number of medals per team and the number of athletes per team (GroupBy and Math Formula nodes). For question 2, we use the GroupBy node to aggregate the athletes' data based on sport and year, use two instances of the Row Filter node to isolate sports that were present up to 2012 and those that were present in 2016, and then compare these two lists to identify those sports that only started in 2016 (Joiner node). Finally, for question 3 we use the Row Filter node to identify all athletes that are gold medalists, and then sort them based on their age with the Sorter node.
Level: Medium
Description: You work as a data analyst for a delivery company, and some packages were not delivered last week due to address typos. Thanks to the postal carriers, addresses that were not found due to typos were marked as such. Given a dataset with successful deliveries (due to no typos) and unsuccessful ones (due to typos), your goal is to automatically fix the incorrect addresses by leveraging the correct ones.
Author: Aline Bessa
Dataset: Postal Data on KNIME Community Hub
Solution Summary: To tackle this challenge, we first separate the addresses that have typos from those that do not. Next, for each address with a typo, we find the correct address that is the most similar to it, and then replace it.
Solution Details: After reading the dataset with postal addresses with the CSV Reader node, we use the Row Splitter node to separate those with typos from those that are correct. Next, we remove duplicate addresses with the Duplicate Row Filter node and use the String Matcher node to identify, for each incorrect address, the most similar correct one. This information is used to fix each incorrect address with the String Replacer (Dictionary) node.
Level: Medium
Description: Recently you became more interested in finance, and since you want to learn more about web scraping for work, you decided to unite both interests. Using the KNIME Web Interaction extension, can you navigate to the Economic News section on Yahoo Finance, extract the headers of only the most recent topics that pop up on the webpage, and then make sense of the results visually? Remember to filter out any ads or unrelated banners/headers/content. Hint: Find class tags in the news' XML that are unique to the content you are scraping.
Author: Thor Landstrom
Solution Summary: To tackle this challenge, we connect to a browser through KNIME Analytics Platform, fetch the most recent content from the Economic News section on Yahoo Finance, extract its headers, and then visualize their corresponding topics as a table.
Solution Details: We start our solution by connecting to a browser with the Web Interaction Start node. We then navigate to the Economic News page on Yahoo Finance using the Navigator node. We retrieve the XML content of this page, including heading tags and text, with the Content Retriever node. In parallel, since we do not need a browser connection anymore, we close it with the Web Interaction End node. As for the retrieved content, we use the Row Filter node to remove headings that are not tagged as "h3", and then a combination of the XPath node and a second instance of the Row Filter node to identify and remove rows that contain ads or unrelated pages. Finally, we isolate the heading texts with the Column Filter node and visualize them as a table with the Table View node.
Level: Medium
Description: You are reorganizing a data warehouse in your company, working with a filesystem that creates parent folders if you give it a reference for a child folder. For example, if you ask the filesystem to create “folder1/folder2” and neither folder1 or folder2 exist, it will create both, with folder2 inside folder1, without raising an error. Given a list of folders, you want to keep only the longest unique child folders, filtering out references to parent folders that will be generated anyway for efficiency.
Here's an example of an initial list of folders:
- folder1/folder3
- folder1/folder3/folder22
- folder1/folder3/folder22/folder47
After executing your workflow, the list above should only contain a reference for folder1/folder3/folder22/folder47.
Author: Emilio Silvestri
Datasets: Folder Data in the KNIME Community Hub
Solution Summary: After reading the list of folders, we calculate the depth (number of levels) for each one of them. Next, we iterate over all folders searching for parent folders and making sure that we just keep the "deepest reference" with a path in common. We also create references for paths that got excluded, indicating what redundant child/subfolder was responsible for it.
Solution Details: After reading the list of folders with the Table Reader node, we split them into columns with the Cell Splitter node and, with a combination of nodes (Column Aggregator, Math Formula, Column Filter), end up with the number of levels (depth, or cardinality) present in each folder reference. Next, we use the Table Row to Variable Loop Start and Variable Loop End nodes to iterate over all folders. At each interaction, we use the String Manipulation and Row Filter nodes to find and isolate all parent folders for the folder in question. By combining the Table Row to Variable and Rule Engine Variable nodes, we make sure that we just keep the folder in question if it is the deepest, using identified parent folders as comparison.
Level: Medium
Description: You work as a freelance photo reporter for wildlife magazines. In your daily work you take a lot of pictures, usually in .JPG format and in different sizes. To be able to sell your photographs to magazines, you need to accommodate their different sizing and formatting requests. To streamline this process, you decide to build a workflow that automates the following, sequentially: (1) Image resizing -- create a configurable component with three options: do nothing, reduce to fixed size (150x150), or reduce size keeping ratio; (2) image format conversion -- create a configurable component with two options: .PNG or .SVG; (3) save edited images on your machine.
Author: Roberto Cadili
Datasets: Image Data in the KNIME Community Hub
Solution Summary: Our solution to this challenge contains two configurable components that let users (1) resize their images in different ways (do nothing, keep the ratio, or use a fixed 150x150 format), and then (2) convert them into .PNG or .SVG format. The images are then saved locally.
Solution Details: We start our solution by using the List Files/Folders node to get a list of local images in .JPG format. We then use the Path to String node to facilitate the reading of these images, and import them to KNIME Analytics Platform with the Image Reader (Table) node. The images are sent to our first component, Image Resizer. With the Single Selection Configuration node, we allow users to configure this component based on resizing option (do nothing, keep the ratio, or use a fixed 150x150 format). A CASE Switch Start node gets the chosen option and either activates no branch, going straight to the CASE Switch End node, resizes the images in a fixed way with the Image Resizer node, or resizes the images using a ratio of 0.3 also with another instance of the Image Resizer node. The resized images are then passed to a second component, named Image Converter. This component also uses an instance of the Single Selection Configuration node to let users pick the format they want the images to be in (.PNG or .SVG). The images inside the component are initially converted to .PNG and then passed as input to an instance of the CASE Switch Start node. If the chosen option is .PNG, this node activates a branch that simply ungroups the images with the Ungroup node. If the chosen option is .SVG, the images are also ungrouped with another instance of the Ungroup node but are turned into .SVG with the Renderer to Image node. Both branches meet as inputs for the CASE Switch End node. Outside this second component, we use the String Manipulation node to create a filename column, and then save the edited images locally with the Image Writer (Table) node.
Level: Medium
Description: As the 2024 European Football Championship (UEFA) unfolds, let's dive into football history with a data challenge. Today you are asked to create a data app that allows users to check, for any timeframe, what the top three teams with the most football victories were. Who are the top three teams of all time? And who were the top three teams in the 1980s?
Author: Michele Bassa
Datasets: Football Data in the KNIME Community Hub
Solution Summary: After reading the football data and determining wins, losses, and ties, we create a data app that allows users to pick a temporal interval and then check which three teams had the most victories.
Solution Details: We start our solution by reading the football data with the CSV Reader node, transforming dates into Date format in the node's Transformation tab. Next, we use the Rule Engine node to determine wins, losses, and ties for home teams. This data is then sent to a component (data app) that allows for the temporal filtering of the data. Two instances of the Date&Time Widget node let users select the start and end dates of a temporal period, for which a team ranking will be calculated. The selected dates are passed to two instances of the Date&Time-based Row Filter node, reducing the data to a specific period. After that, two parallel branches use the Row Filter, Column Filter, and GroupBy nodes to select those matches in which the home team (top branch) or away team (bottom branch) wins. Both victory numbers are combined with the Joiner node, and then the Top k Row Filter node selects the top three best teams for the selected period. This information is then plotted with the Bar Chart node.
Level: Medium
Description: As a member of a think tank, your task is to craft a report on LGBTQIA+ representation in political discourse. Given a EU dataset gathering responses from LGBTQIA+ individuals across all member states, you decide to start your work by investigating the answers to the following question: "In your opinion, how widespread is offensive language about lesbian, gay, bisexual, and/or transgender people by politicians in the country where you live?”.
Use a map to present the results effectively.
Author: Michele Bassa
Datasets: LGBTQIA+ Survey Data in the KNIME Community Hub
Solution Summary: To tackle this challenge, we reduce the scope of the data to question "In your opinion, how widespread is offensive language about lesbian, gay, bisexual and/or transgender people by politicians in the country where you live?". We then filter the answers and only keep the most common ones: "rare" and "widespread". This facilitates the understanding of trends and patterns across countries. We compute the percentages of answer "widespread" for every country and also compute their map coordinates. Finally, we join the geospatial information and the computed percentages and plot them in a map.
Solution Details: After reading the survey dataset with the CSV Reader node, we prepare the data by reducing it to question "In your opinion, how widespread is offensive language about lesbian, gay, bisexual and/or transgender people by politicians in the country where you live?", and to its two most common answers, "rare" and "widespread". We also group the data by country, keeping the totals for both answers. We loop over this data (Group Loop Start and Loop End nodes) to compute the percentages of answer "widespread" for every country, using the Math Formula node (we compute the denominator for these percentages with the Moving Aggregator node). Next, we run another loop (Table Row to Variable Loop Start and Loop End nodes) to find the map coordinates of each country with the OSM Boundary Map node. We join the previously calculated percentages to the data with the map coordinates (Joiner node), use the Projection node to improve formatting for visualization, filter irrelevant data with the Row Filter node, and then finally plot the computed information with the Geospatial View node.
Level: Medium
Description: You work for the United Nations and want to discuss how the causes of death vary across the European Union (EU). You know how to analyze data and generate insightful visualizations, but the data you have at hand is a bit challenging: the meaning of its different columns and codes is not clear. To conclude your work well, you will have to integrate this data with some metadata in XML format, making sense of the different death causes and data attributes. What patterns can you find in the different countries?
Author: Emilio Silvestri
Datasets: Demographic Data from the EU in the KNIME Community Hub
Solution Summary: Our solution to this challenge can be split into two steps. First, we identify the code for the top cause of death in each country, regardless of sex or age; next, we match these codes with metadata describing what they are and sort the countries based on these descriptions. For 27 (out of 35) countries, "diseases of the circulatory system" is the main cause of death; for 8 (out of 35) countries, the top cause of death is "neoplasms".
Solution Details: With the CSV Reader node, we ingest the dataset on EU death causes in 2021. Next, with a series of Column Filter and Row Filter nodes, we reduce the dataset to what is pertinent to the analysis. It lists codes for causes of death per country regardless of sex and age. We then use a loop (Group Loop Start and Loop End nodes) to identify what is the top code for cause of death per country, employing the Top k Row Filter node. At the end of this branch, we have the codes that correspond to top death causes all over the EU, but cannot make sense of them yet. To this end, in parallel, we ingest metadata on the death causes with the XML Reader node. Using a series of XPath nodes, we extract column names, descriptions, and other values from the metadata. The descriptions and values come in lists, and to facilitate their posterior matching with death cause codes from the original dataset, we use the Ungroup node to break the lists into single tokens. We filter the resulting data to only keep rows that correspond to causes of death (Row Filter node), and then use the Value Lookup node to match these causes with their codes in the original dataset. Finally, we sort the data with the Sorter node and get to the conclusion that the top cause of death in most EU countries has to do with diseases of the circulatory system.
Level: Easy
Description: You are a real estate agent working in a new city, and to perform well your first task involves understanding the houses in the region better. A colleague shares a dataset with you and now it’s time for you to explore it. What has been the average housing price, lot size (in acres), and living space (in sqft) in this city, according to her dataset? How are prices distributed and correlated with housing features? What other insights can you gather from this dataset?
Author: Thor Landstrom
Dataset: Real Estate Data in the KNIME Community Hub
Solution Summary: To tackle this challenge, we compute some general statistics of the dataset such as average price, lot size, and living space. We also calculate the linear correlation for all pairs of numerical features, uncovering which housing attributes have the largest connection with their price. On average, central Seattle is the priciest area in the region, but there are a few other relevant clusters to the south and to the east.
Solution Details: After ingesting the housing data with the CSV Reader node, we compute Pearson's linear correlation for all pairs of numerical attributes with the Linear Correlation node. The results are plotted with the Heatmap (JavaScript) node, revealing which housing attributes relate the most to their price. In parallel, we use the Column Filter node to remove unnecessary columns, and convert the lot size information into acres with the Math Formula node. We use the Statistics View node to get important housing summaries, including their average lot size and price, and group the data with the GroupBy node by zipcode. In the aggregation, we calculate the average housing price per zipcode and their median latitude and longitude values. The Lat/Lon to Geometry node uses the median values per zipcode to generate geometries, which are then visualized with the Spatial Heatmap node.
Level: Easy
Description: You are a climate scientist studying CO₂ emissions. To make your research insights more accessible to your colleagues, and then write a paper about it, you decide to build a report-enabled component in KNIME that allows users to check how emissions vary for different regions and sources. What are the most alarming insights illustrated in such report?
Authors: Armin Ghassemi Rudd and Marina Kobzeva
Dataset: CO₂ Emissions Data in the KNIME Community Hub
Solution Summary: To tackle this challenge, we manually select the country that ranks highest in terms of CO₂ emissions and create a PDF report showing its historical emissions, how they vary per capita throughout the years, and what sources they are mostly tied to. Different countries can be selected based on their ranking, leading to different visualizations and reports.
Solution Details: After reading the dataset with the Table Reader node, we use the Row Filter node to select a country based on its CO₂ emissions' ranking. Next, we finish our preprocessing by using the Number Format Manager node, selecting how many decimals we want to use in the CO₂ and CO₂ per capita numbers of our report. We create a component named "Report" that contains a few visualizations for our data: two line plots (Line Plot node) for the historical emissions of CO₂ and CO₂ per capita, and a bar chart (Bar Chart node) showing a breakdown of these emissions for different sources. To turn these visualizations into a PDF report, we feed this component with a report template (A4 Landscape) that is specified with the Report Template Creator node. After the component executes, its visualizations are saved as a PDF report with the Report PDF Writer node.
Level: Easy
Description: You work in finance and one of your clients wants to understand the value of different company stocks over time. Given a dataset of stock prices, you decide to use simple moving averages (window length = 20) to tackle this task. What companies have an upward trend for the most recent data? And what companies have a downward trend?
Author: Thor Landstrom
Dataset: Stock Data in the KNIME Community Hub
Solution Summary: We propose two different solutions to this challenge. The simplest one involves manually filtering the data for a specific company, calculating its moving average, and then visualizing it with a line plot. The second one relies on a simple data app: a company is selected from a dropdown box and its stock prices are selected, a moving average is computed, and the final points are plotted as a line plot.
Solution Details: Both solutions have a core part in common. After the rows for a company are selected, we use the Column Filter node to isolate dates and close prices, do some typecasting with the String to Date&Time node, sort the data from oldest to most recent with the Sorter node, and then use the Moving Average node to compute simple moving averages (window length = 20). Next, we visualize the results with the Line Plot node. In the simplest solution, we use the configuration of the Row Filter node to select the data for a company. In the more complex solution, we get all company names with the "Get company names" metanode, and then pass them, along with the original data, to the "Visualize company stock prices" component. Inside this component, a Single Selection Widget node allows the selection of one of the company names, which in turn is used to control an instance of the Row Filter node. After that, this solution is basically equivalent to the simplest one.
Here is how the challenges work:
⇒ We post a challenge on Wednesday.
⇒ You create a solution with KNIME Analytics Platform.
⇒ Upload it to your public KNIME Community Hub Space.
⇒ Check your rank on the Just KNIME It Leaderboard.
Our solution to the challenge comes out on the following Tuesday.
